| Item |
Unit |
Parameter |
| Engine |
/ |
Weichai WP10HG313E672 |
| Rated power |
kW |
230 kw/2200 rpm |
| Power head Max. thrust-pull force |
kN |
/ |
| Power head Max. thrust-pull speed |
m/min |
/ |
| Power head Torque |
N·m |
/ |
| Power head Max. rotation speed |
r/min |
/ |
| Mud pump Max. flow |
L/min |
800 L/min |
| Mud pump Max. pressure |
MPa |
10 MPa |
| Crane Lifting weight |
t |
/ |
| Crane Lifting moment |
t•m |
/ |
| Recommended drill pipe |
mm×m |
/ |
| Max. entry angle |
° |
/ |
| Max. back reaming diamete |
mm |
/ |
| Weight |
t |
/ |
| Outline dimensions |
mm |
/ |
| Engine Power |
kW |
/ |
| Engine Model |
一 |
/ |
| Max.Thrust-pull Force |
kN |
/ |
| Max.Thrust-pull Speed |
m/min |
/ |
| Max.Torque |
N ·m |
/ |
| Max.Rotation Speed |
r/min |
100 r/min |
| Max.Mud Flow |
L/min |
800 L/min |
| Max.Mud Pressure |
MPa |
10 MPa |
| Drill Pipe |
mm×m |
Φ 114/127 (optional) x 6 m |
| Max.EntryAngle |
一 |
18° |
| Max.Reaming Diameter |
mm |
Φ1200mm |
| Weight |
kg |
20t |
| Dimensions（L×W×H） |
mm |
10780x2850x2770 |
