XDN2000-S
1. The electric drive flat pipe jacking machine is mainly suitable for common soil layer and sand layer, especially with high construction efficiency in silt and quicksand strata. 2. The excavation face has good supporting effect, the ground settlement is small and the surface deformation is controllable. 3. The cutterhead speed, jacking speed, and mud feed and discharge flow can be adjusted steplessly, with good equipment maneuverability. 4. The human-machine interactive console dynamically displays the operating parameters and working status of each component.
Parameters
| Item | Unit | Parameter |
|---|---|---|
| OD×length | mm | Φ2420×4100 |
| Power | kW | 37×2 |
| Max. torque | kN·m | 294 |
| Max. speed | r/min | 4.8 |
| Steering thrust | t | 120×4 |
| Steering angle | ° | 3 |
| Mud pipe diameter | mm | Φ125 |
