XE220EN
With high pressure common-rail electronic injection engine that meets EU stage-V emission standards equipped, XE220 EN crawler excavator achieves the best fuel injection control, improving combustion efficiency, saving energy and protecting environment. Equipped with a new large diameter multi-way control valve, the hydraulic system is quick and efficient; internal pressure loss of the channel is reduced due to the further optimization of the valve element, so the excavator maneuverability and composite operation efficiency are improved. Centralized lubrication on lubrication points of the working device makes it easy for lubrication.
Parameters
| Item | Unit | Parameter |
|---|---|---|
| Operating weight | Kg | 23400 |
| Rated power | kW/rpm | 129 |
| Engine model | – | Cummins B6.7 |
| Bucket capacity | m³ | 1.05 |
| Emission standard | – | Euro V |
| Maximum torque/speed | N.m | 881/1300 |
| Displacement | L | 6.7 |
| Travel speed | km/h | 5.4/3.5 |
| Swing speed | r/min | 11.8 |
| Bucket digging force | kN | 149 |
| Arm digging force | kN | 111 |
