| Item |
Unit |
Parameter |
| Working Height |
mm |
58600 |
| Lift capacity |
kg |
230(unlimited)/450(limited) |
| Weight |
kg |
27900 |
| Overall dimension-Stowed |
mm |
19450x2490x3070 |
| Overall dimension-Transportation |
mm |
14600x2490x3070 |
| Dimension of working platform |
mm |
2400x900x1150 |
| Wheelbase |
mm |
5220（Axle retracted）4590（Axle extended） |
| Overall Width |
Axle retracted/Axle extended |
2490mm/5030mm |
| Fly jib length |
mm |
3970(Axle retracted)/5970（Axle extended） |
| Ground clearance |
mm |
250 |
| Max.Platform height |
m |
56.6 |
| Max.Working range |
m |
24.4 |
| Max.Occupants |
– |
3 |
| Max.Working slope |
– |
X-3°/ Y-3° |
| Telescopic boom luffing range |
– |
-1～+80° |
| Flying jib luffing range |
– |
-45°~+75° |
| Turntable rotation |
– |
360° |
| Platform rotation |
– |
160° |
| Drive speed |
stowed |
4.5km/h |
| Drive speed |
Up or extended |
0.5km/h |
| Min.Turning radius-Axle retracted |
inside/outside |
13810mm/17140mm(2-wheel) 7100mm/9500mm(4-wheel) |
| Min.Turning radius-Axle extended |
inside/outside |
2800mm/9200mm(2-wheel) 2300mm/6600mm(4-wheel) |
| Turntable tailswing |
Axle retracted/Axle extended |
2320mm/1050mm |
| Max.Gradeability |
– |
45% (24°) |
